TCT Three-Edged Staggered Tooth Straight Cutter
1/2 Shank TCT 3 Flute Straight Cutter
Milling Cutter Carbide Straight End for Wood
Woodworking Trimming Engraving Slotting Milling Cutter
Description
Brand: YD
Material: Shank steel body + Cutting edge integral alloy
Features: Precise three edge broken tooth spacing, fast chip breaking, chip removal, three edge at the same time to participate in cutting, enhance cutting force, reduce resistance, reduce noise, make the surface smooth, smooth inner wall, high finish.
Applicable sheet: Multi-layer board, large core board, particle board, MDF, MDF, etc..
Specification
| Specification | Cutting Diameter | Blade Height | Shank Diameter |
| Size | D (mm) | H (mm) | d (mm) |
| 1/2*5*20 | 5 | 20 | 1/2 |
| 1/2*6*20 | 6 | 20 | 1/2 |
| 1/2*6*22 | 6 | 22 | 1/2 |
| 1/2*6*25 | 6 | 25 | 1/2 |
| 1/2*6*28 | 6 | 28 | 1/2 |
| 1/2*6*30 | 6 | 30 | 1/2 |
| 1/2*6*40 | 6 | 40 | 1/2 |
| 1/2*7*20 | 7 | 20 | 1/2 |
| 1/2*7*22 | 7 | 22 | 1/2 |
| 1/2*7*28 | 7 | 28 | 1/2 |
| 1/2*7*30 | 7 | 30 | 1/2 |
| 1/2*8*20 | 8 | 20 | 1/2 |
| 1/2*8*22 | 8 | 22 | 1/2 |
| 1/2*8*25 | 8 | 25 | 1/2 |
| 1/2*8*30 | 8 | 30 | 1/2 |
| 1/2*8*32 | 8 | 32 | 1/2 |
| 1/2*8*35 | 8 | 35 | 1/2 |
| 1/2*8*40 | 8 | 40 | 1/2 |
| 1/2*8*45 | 8 | 45 | 1/2 |
| 1/2*8*50 | 8 | 50 | 1/2 |
| 1/2*9*30 | 9 | 30 | 1/2 |
| 1/2*9*35 | 9 | 35 | 1/2 |
| 1/2*9*40 | 9 | 40 | 1/2 |
| 1/2*10*30 | 10 | 30 | 1/2 |
| 1/2*10*35 | 10 | 35 | 1/2 |
| 1/2*10*40 | 10 | 40 | 1/2 |
| 1/2*10*45 | 10 | 45 | 1/2 |
| 1/2*10*50 | 10 | 50 | 1/2 |
| 1/2*12*30 | 12 | 30 | 1/2 |
| 1/2*12*35 | 12 | 35 | 1/2 |
| 1/2*12*40 | 12 | 40 | 1/2 |
| 1/2*12*50 | 12 | 50 | 1/2 |
| 1/2*12*60 | 12 | 60 | 1/2 |
About Shipping: BY AIR / BY SEA / BY EXPRESS
We will choose the most economical express company to ship our products to our customers quickly and safely.
YIDIAN provides a wide range of consumable accessories, tools and spare parts for woodworking machine such as CNC machines, beam saws, edge banding machines, molders. etc. A range of replacement cups and rubber pads for Homag, Weeke, Biesse, SCM and other brands woodworking machines for sale here. YIDIAN is a reliable source for CNC & Woodworking machine spare parts, welcome to contact us.
|
|
TCT Three Flutes Router Bit 1/2 Shank Milling Cutter Carbide Straight End mill for Wood Images
|
